Ford Ranger
(2022+)

Ford Ranger
(2022+)

Ford Ranger
(2022+)

SpartanBar

The Ford Ranger SpartanBar has been developed to offer a durable and lightweight bull bar. Suitable for all Next-Gen models (excluding Raptor) the SpartanBar is designed, engineered and manufactured in Australia to compliment the styling of the Next-Gen Ranger and provide superior protection.

Designed utilising a unique hollow construction and constructed from a tough, corrosion and rust-resistant UV-stabilised polymer, SpartanBars provide frontal protection for your vehicle with the ability to absorb impact and return to shape in the case of an incident. Thanks to their lightweight properties, the SpartanBars assist with minimising the vehicle GVM, improving fuel economy and reducing tyre and brake wear compared to alternative bull bars.

The SpartanBar is the perfect solution for all your rural and remote travel, off-roading, touring and fleet vehicle protective needs.

Find Your Local Stockist
Why Smartbar?

Compatibility

  • Accommodating the fitment of a range of aftermarket safety and 4x4 accessories, the SpartanBar is available in winch and non-winch compatible variants
Why Smartbar?

Safety

  • Compatible with all Ford Advanced Driver Assistance Systems (ADAS). All SpartanBars come with an integrated Radar & Camera housing
Why Smartbar?

Style

  • Designed and uniquely styled to seamlessly fit the shape and aesthetics of the Next-Gen Ford Ranger
Ford Ranger SpartanBar Etch

Driving Light Compatible

Supplied with an accessory mounting bracket to suit a range of driving lights and other 4x4 accessories. (Not compatible with light bars)

Driving Light Compatible

Supplied with an accessory mounting bracket to suit a range of driving lights and other 4x4 accessories. (Not compatible with light bars)

Superior Frontal Protection

Superior frontal protection due to the impact absorbing hollow construction

Aerial Mount Bracket

Aerial mounts are incorporated into the SpartanBar in 4 locations (2 x inner + 2 x outer). A single inner aerial mount bracket is supplied with SpartanBar. Additional mounts can be purchased on request.

Winch Compatible

Available in both a winch and non winch compatible bar. The SpartanBar winch variant is compatible with winches rated up to 10,000lb

4-in-1-Light

All Next-Gen Ranger SpartanBars come standard with a 4-in-1-light. This includes a daytime running light, fog light, park light and indicator functions. The 4-in-1-Light comes with a 5 year warranty

Camera and Radar Housing

The Next-Gen Ranger camera and radar sensor have been relocated and mounted to the top of the bar for complete safety compatibility

Features

  • Supplied antenna mounting bracket
  • Supplied with under centre cover to protect under the vehicle between the chassis rails
  • Bar adds 250mm to vehicle length
  • Bar adjusts approach angle to 25 degrees on centreline
  • Proudly designed and manufactured in Australia
  • Suits all variants except Raptor
Download Spec Sheet

Stay in touch

  • This field is for validation purposes and should be left unchanged.

By clicking above, you agree that we may process your information in accordance with these terms.

Learn more about our privacy policy.

StealthBar

Built to be versatile, to suit your Next-Gen Ford Ranger. The StealthBar is a lighter, streamlined bull bar made to protect your vehicle. Designed, engineered and manufactured in Australia, the StealthBar is a tough, low-profile bar that seamlessly fits the Ranger’s aesthetics.

Designed with a unique hollow construction and built from a tough, corrosion and rust-resistant UV-stabilised polymer, StealthBars provide superior frontal protection for your vehicle with the ability to flex and absorb on impact and then return to shape in the case of an accident. Thanks to their unique lightweight construction, StealthBars assist with improving your fuel economy and reducing tyre, suspension, and brake wear.

The StealthBar is a streamlined platform, perfect for mounting your 4×4 accessories and offering a tough, lightweight alternative for protecting your vehicle and pedestrians.

Find Your Local Stockist
Why Smartbar?

Compatibility

  • A streamline platform for a range of 4x4 driving lights, underbody protection, and available in both winch and non-winch variants.
Why Smartbar?

Safety

  • Compatible with all Ford Advanced Driver Assistance Systems (ADAS). All StealthBars come with an integrated Radar & Camera housing
Why Smartbar?

Style

  • Designed as a low-profile, uniquely styled front bar that seamlessly fits the Next-Gen Ford Ranger
Ford Ranger StealthBar Etch

Winch Compatible

Available in both a winch and non winch compatible bar. The StealthBar winch variant is compatible with winches rated up to 10,000lb

Winch Compatible

Available in both a winch and non winch compatible bar. The StealthBar winch variant is compatible with winches rated up to 10,000lb

Superior Frontal Protection

Superior frontal protection due to the impact absorbing hollow construction

Aerial Mount Locations

Aerial mounts are incorporated into the StealthBar in 4 locations. A single left hand side aerial mount bracket is supplied with the StealthBar. Additional mounts can be purchased on request.

Camera and Radar Housing

The Next-Gen Ranger camera and radar sensor have been relocated and mounted to the top of the bar for complete safety compatibility

Lighting Accessories

Supplied with an accessory mounting bracket to suit a range of driving lights and other 4x4 accessories. (Not compatible with light bars)

4-in-1-Light

All Next-Gen Ranger StealthBars come standard with a 4-in-1-light. This includes a daytime running light, fog light, park light and indicator functions. The 4-in-1-Light comes with a 5 year warranty

Features

  • Supplied antenna mounting bracket
  • Supplied with under centre cover to protect under the vehicle between the chassis rails
  • Bar adds 230mm to vehicle length
  • Bar adjusts approach angle to 27 degrees on centreline
  • Proudly designed and manufactured in Australia
  • Suits all variants except Raptor
Download Spec Sheet

Stay in touch

  • This field is for validation purposes and should be left unchanged.

By clicking above, you agree that we may process your information in accordance with these terms.

Learn more about our privacy policy.

Under Vehicle Armour

Designed as a complete OE Skid pan replacement for the Next-Gen Ranger, Under Vehicle Armour (UVA) offers superior coverage and levels of protection for the underbody of your vehicle. Constructed from UV stabilised crosslink polymer and designed with a 12mm thick, unique, deep rib structure, it provides continuous strength and protection for your vital components.

Utilising roto-moulding manufacturing technologies enables UVA to be uniquely shaped and sized, designed specifically for each vehicle, providing significant surface coverage to the underbody of the Ranger. Constructed using crosslink polymer not only provides robust properties, protecting your underbody from rock, stumps, ruts and other hazards whilst keeping your GVM and repair costs low. It also allows the UVA to absorb impact, reducing shock to the vehicle and can re-form to it’s original shape.

Find Your Local Stockist
Why Smartbar?

Unique Construction

  • Utilising roto-moulding manufacturing technologies enables UVA to be uniquely shaped and size, offering increased coverage of the under-body of the Next-Gen Ranger compared to alternative products
Why Smartbar?

Serviceability

  • Made up of three individual parts, the UVA is designed for serviceability. Each piece has been designed so that it can be removed and easily allow access to different underbody components
Why Smartbar?

Durability

  • The polymer's inherent properties are resistant to heat, corrosion and rust, providing the ultimate solution for protecting those vital components on the underbody of your Ford Ranger.
Ranger:EverestUVA Etch

Light Weight

Weight savings provide improved fuel economy and reduced tyre, suspension and brake wear when compared to other after market alternatives

Light Weight

Weight savings provide improved fuel economy and reduced tyre, suspension and brake wear when compared to other after market alternatives

Deep Rib Structure

Deep rib structure provides continuous reinforced strength for your vital components

ARB Recovery Points

Compatible with either one or two ARB Recovery Points

Strong Bracketry

Durable, strong bracketry to protect under body components against impact

Easily Disassembled

Made up of three individual parts, the UVA is designed for serviceability. Designed to allow easy access to different parts of the vehicle

Features

  • Compatible with ARB recovery points
  • Compatible with ARB bull bars and OEM bumper
  • Easily disassembled for vehicle servicing and access
  • Durable, strong bracketry to protect under body components
  • Minimal repair costs after impact
Download Spec Sheet
